Camera
-
Image Sensor: 1/3" Progressive Scan CMOS
-
Effective Pixels: 1920(H)*1080(V)
-
Min. Illumination: 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR
-
Shutter Time: 1/25(1/30) s to 1/50,000 s
-
Lens: 3.6mm (2.8mm, 6mm, 8mm optional)
-
Angle of View: 80.9°(3.6mm), 103.5°(2.8mm), 54.3°(6mm), 38°(8mm)
-
Lens Mount: M12
-
Day& Night: IR cut filter with auto switch
-
Wide Dynamic Range: 120dB
-
Video Frame Rate: 1080p@25fps/1080p@30fps
-
HD Video Output: 1 Analog HD output
-
Synchronization: Internal Synchronization
-
Video Output: 1Vp-p Composite Output (75Ω/BNC)
-
S/N Ratio: More than 52dB
-
Up the Coax: Support
Menu
-
Camera ID: On/off (15 characters, position programmable)
-
D/N Mode: Color/ BW/ EXT
-
Auto White Balance: ATW/ AWC-SET/ Indoor/ Outdoor/ Manual
-
Private Mask: On/Off, maximum 8 zones
-
Motion Detection: On/Off, maximum 4 zones
-
BLC: On/Off
-
AGC: Support
-
Anti-flicker: On/ Off
-
Language: English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic
-
Scene: Indoor, Outdoor, Indoor1, LOW-LIGHT
-
Function: Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM
General
-
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F)
-
Humidity 90% or less (non-condensing)
-
Power Supply: 12 V DC±10%
-
Power Consumption: Max. 4W
-
Weather Proof: IP66
-
IR Range: Up to 20m
-
Dimension: 94.6×83×210.8mm(3.72”×3.27”×8.30”)
-
Weight: 700 g (1.54 lbs
-
